Custom Large-Scale Bellows

Dynatect’s Large-scale bellows solutions are ideal when the container is being converted to a facility enclosure

• Cargo crates
• Classrooms
• Disaster relief
• Hospitality room
• Mobile hospitals (including mobile MRI / CT-scan)
• Mobile command and control centers
• Offices
• Oil & Gas camp
• Remote service station
• Tiny-home, cabins, vacation rentals
• Shipping containers
• Intermodal containers
• Trailers
• Train containers
• Training facilities
• Modular spaces
• Cargo boxes

Features

• Construction: Made from a strong, lightweight aluminum reinforced structure with durable CSM coated fabric
  • Translucent fabric available to allow ambient light
  • Structural floors available
• Adaptability: Bellows adjust to typical multi-axis misalignment of modular spaces
• Integrity: Reinforced for environmental loading including rain/wind/snow
• Durability: Capable of handling varying temperatures from -30˚F to 130˚F, and UV resistant
• Customization: Variable cross sections, lengths, and mounting designs available. The bellows is customized and manufactured to your specific parameters and mounting requirements.
• Portability: Engineered for compressed shipment, fast installation, and reusability

Benefits

• Efficiency: Mobile building bellows result in fewer external doors
• Safety: Protects occupants from rain, heat, wind, snow and stairs when transitioning between spaces
• Energy Costs: Reduces losses in temperature- and humidity-controlled rooms
• Cleanliness: Limits external environmental contaminants (surgical, food prep, electronics)
• Acoustics: Minimizes exposure to outside noise and frequency of door operations (construction, high traffic)
• Asset Reuse: Connects to existing structures with custom mounting designs and are reusable

Please provide the following information using our quote request form (PDF)

Basic Application Information

• Do you have an existing design?
• Quantity
• What is your project timeline?
• Describe your application
• What is the temperature range?
• Are there any special environmental considerations?
• Regulatory requirements (e.g. flame retardancy)?
• Note that Dynatect bellows are designed to protect occupants from typical outdoor conditions of rain, heat, wind, and snow. They are also capable of handling varying temperatures from -30˚F to 130˚F and are UV resistant

Measurements

Refer to figures A, B, C, D – Click image for larger size in separate tab

1. (Fig. D) Horizontal installed Distance
   HiD min : _________ HiD max : _________
2. Stored maximum compressed length: _________
3. (Fig. A) Exterior height restriction / max. height:_________
4. (Fig. C) Exterior width restriction / max. width: ________
5. (Fig. B) Passage clearance required…
   height: _________ width: _________
6. (Fig. B) Maximum bellows overall…
   height: _________ width: _________
7.  (Fig. C) Maximum horizontal face angular offset between structures: _________ degrees
8. (Fig. A) Maximum vertical face angular offset between structures: _________ degrees
9. (Fig. B) Maximum horizontal offset between structures: _________
10. (Fig. D) Maximum vertical offset between structures
    V min : _________ V max. : _________
11. (Fig. B) Maximum bottom clearance: _________

Our Container/Building Bellows are flexible connecting bellows that link modular structures such as shipping containers, mobile offices, and emergency shelters. These bellows create enclosed walkways that improve environmental control, privacy, and sanitation.

Check out our Shipping Container Bellows page for more!
